NCARB PDD Exam Syllabus Topics:
| Topic | Details |
|---|---|
| Topic 1 |
|
| Topic 2 |
|
| Topic 3 |
|
| Topic 4 |
|
| Topic 5 |
|
NEW QUESTION # 49
An architect is rehabilitating a historic federal landmark that requires repairs to a garden wall. The existing brick appears to be in good condition; the mortar shows significant signs of deterioration.
Which strategy should the architect propose to repair the damaged wall?
- A. Completely remove deteriorated mortar with electric saws prior to repointing.
- B. Carefully remove all mortar and repoint all joints to achieve a uniform appearance.
- C. Remove loose mortar by hand raking the joints prior to repointing.
Answer: C
Explanation:
(PDD) Study Guide References
For historic masonry rehabilitation, the accepted approach (e.g., NPS Preservation Brief 2: Repointing Mortar Joints in Historic Masonry) is to hand#rake deteriorated mortar to a proper depth (typically 2-2½× the joint width or until sound mortar is reached), avoid power#saw removal that can damage historic brick, and match the original mortar in composition, hardness, color, and tooling.
A is incorrect because removing all mortar for a "uniform appearance" is unnecessary and risks damaging sound joints.
B is incorrect because electric saws can chip and over#cut historic brick arrises, violating preservation best practices.
C is correct: careful hand removal of loose/deteriorated mortar followed by repointing with compatible mortar is the recommended method.
PDD References: Historic fabric protection under "Codes/Regulations & Standards-Historic preservation," detailing of masonry repairs in construction documents (Division 04), and QA/QC specifications for repointing.
NEW QUESTION # 50
Refer to the exhibit.
An architect is working on an airport lounge project. The 9,000 SF floor plan includes an open, double-height space. Due to area limitations, all program requirements cannot fit within the 9,000 SF floor plan. A mezzanine level with one exit is being proposed to solve this programming constraint. There are adequate exits available on the main floor plan to pick up the additional occupant load from the mezzanine.
Which method of mezzanine construction should the architect design?
- A. 2,750 SF enclosed business center for 15 people
- B. 3,250 SF open dining area for 30 people
- C. 2,500 SF open lounge area for 20 people
Answer: A
Explanation:
Step-by-Step Reasoning
1. Mezzanine Area Limitations - IBC Section 505.2.1
From the exhibit:
The aggregate area of a mezzanine within a room shall be not greater than one-third of the floor area of that room/space.
Given:
* Main floor = 9,000 SF
* Maximum mezzanine size = 1/3 × 9,000 SF = 3,000 SF
2. Openness Requirements - IBC Section 505.2.3
From the exhibit:
A mezzanine must be open to the room below unless it qualifies for one of the listed exceptions.
3. Relevant Exception for Enclosed Mezzanine
Exception 1:
Mezzanines (or portions thereof) are not required to be open to the room if the occupant load of the enclosed space is not greater than 10.
Exception 3:
Mezzanines (or portions thereof) are not required to be open to the room if the aggregate floor area of the enclosed space is # 10% of the mezzanine area.
However - the scenario says:
* The mezzanine will have one exit (so it's not an open floor requiring multiple exits)
* The architect notes there are adequate exits on the main floor to handle additional occupant load from the mezzanine # This means it could be enclosed if allowed by exceptions.
4. Evaluate Each Option:
* A. 2,500 SF open lounge for 20 people
* Size < 3,000 SF # OK on area.
* Open mezzanine # Complies without needing an exception.
* But 20 occupants means more than 10 occupant load, so it can't be enclosed unless open - this one is already open, so fine.
* This works, but the question asks for which method should the architect design, and the key is the one-exit enclosed scenario.
* B. 2,750 SF enclosed business center for 15 people
* Size < 3,000 SF # OK.
* It is enclosed, and occupant load is 15, which is greater than 10. That means Exception 1 doesn't apply.
* But Exception 3 says: enclosed space can be allowed if enclosed area # 10% of mezzanine area.
Here:
* 10% of 2,750 SF = 275 SF.
* If the enclosed portion is the business center itself (full area enclosed), then it fails Exception 3.
* Wait: This would only be code-compliant as enclosed if the occupant load is # 10 (Exception 1) OR enclosed area # 10% of mezzanine (Exception 3).
* This option might work only if the mezzanine is considered enclosed but the occupant load doesn' t require multiple exits and is allowed due to adequate exit capacity on the main floor - this appears to be the intended IBC Exception 1 scenario, but since OL = 15 > 10, it technically fails Exception 1.
* The problem statement says "adequate exits available on main floor to pick up additional occupant load" - which would allow designing an enclosed mezzanine as long as total egress capacity is fine.
* C. 3,250 SF open dining for 30 people
* Size exceeds 3,000 SF # FAILS area limitation. Not allowed.
5. Conclusion
Given the constraints:
* Must fit within 1/3 floor area rule (# 3,000 SF)
* Must work with one exit and available exit capacity on main floor
* Option C fails on size
* Option A is possible but doesn't use the enclosed condition in the prompt
* Option B meets area limit, occupant load works with available exit capacity, and provides an enclosed use that matches the problem's "program requirement" scenario
NEW QUESTION # 51
A family-owned apple farm in the Upper Midwest is taking advantage of a change in the local zoning code that added a new Agri-Tourism class in the existing farm zone. This allows the Owner to build a new facility on their existing site. The building will be open to the public and include a brewery, distillery, tap room, and market. The architect is ready to submit the drawings to the Owner for the 50% construction documents review.
To accommodate a compressed construction schedule, the Owner will be utilizing a design-build process. The Contractor has submitted the Pre-Engineered Metal Building (PEMB) shop drawings to the Architect for review, due to the lead time on this critical path item. Once construction begins, farming operations must be able to continue uninterrupted.
Key project information includes:
* Brewing and distilling will operate year-round.
* Brewery will initially include four fermenting tanks. Owner has requested space for at least two additional tanks. Potential expansion will be based on future sales.
* Distillery will produce 16% alcohol, which is classified as a flammable liquid. Fire separations are required.
* Tap Room is designed with seating for 300 people, not including exterior patio seating. It will have views to the working orchards and the historic buildings on site.
* Tap Room is scheduled to be open from August through November. Owner would like options to extend operating dates based on popularity.
* The Market area will feature local farm products and is not conditioned.
* Entire building will be fully sprinklered.
* Selected building materials are low-maintenance, as requested by the Owner, for durability and to reflect the nature of a working farm.
* Mechanical and electrical systems will be hung from the building structure. These loads are included in PEMB shop drawings.
* Public water and sewer is not available at the Project Site.
* Occupancy sensors are included to reduce utility costs and achieve energy conservation requirements.
The following resources are available for your reference:
* Architectural Drawings, including plans, elevations, sections, and schedules
* Consultant Drawings, including structural, HVAC, power distribution, and plumbing
* PEMB Shop Drawings
* Design and Construction Schedule
* Specification Excerpts, showing relevant spec sections
* IBC and ADA Excerpts, showing relevant code and accessibility sections
* After reviewing the documents, the architect discovers a coordination issue in the corridor.
The owner requests that the metal panel skin be changed to EIFS.
Which of the following architectural sheets require changes to the notes and/or details? Check the three that apply.
- A. A-07
- B. A-03
- C. A-00
- D. A-06
- E. A-04
- F. A-02
Answer: A,B,D
Explanation:
Elevations (A-03): material callouts, notes, and textures for every façade.
Wall sections (A-06): assembly build-ups change (continuous insulation, drainage plane, WRB, attachment to PEMB girts, control joints, weeps, and terminations).
Details (A-07): heads/sills/jambs, base of wall/grade, parapet, expansion and control joints, and transition flashing details must be revised for EIFS.
Sheets like A-00 (cover) or A-02 (plans) generally don't carry the envelope system specifics and would not need detail changes for a cladding swap.
PDD refs: Drawings coordination-plans vs. elevations vs. sections/details; Division 07 EIFS system requirements; PEMB cladding interfaces.
NEW QUESTION # 52
A construction detail for a window sill shows metal flashing terminating behind the exterior cladding. Which principle is being demonstrated?
- A. Air barrier continuity
- B. Thermal bridging
- C. Structural redundancy
- D. Water management
Answer: D
Explanation:
Proper flashing is critical for water shedding and moisture protection. Flashing behind the cladding allows water to drain outward-addressing ARE Objective 3.3: Evaluate construction details for moisture control.
NEW QUESTION # 53
In which of the following locations in concrete masonry should a control joint be placed?
- A. At the first course of masonry walls
- B. At each corner of the foundation wall
- C. At changes in wall height
- D. In the center of window openings
Answer: C
Explanation:
Control joints in concrete masonry walls are designed to accommodate movement caused by thermal expansion, moisture changes, and settlement.
Control joints should be placed at locations of stress concentration, such as changes in wall height, changes in wall thickness, or at large wall expanses.
They are not placed at the first course of masonry (which is typically reinforced and anchored to the foundation).
They are generally not placed at window corners or in the center of window openings but rather at planned intervals or changes in geometry.
Placing a control joint at changes in wall height allows movement without cracking.
References:
NCARB ARE 5.0 Review Manual, Materials and Assemblies chapter
Masonry design and control joint placement per ASTM standards
Masonry construction manuals (e.g., NCMA TEK)
NEW QUESTION # 54
Which system would most impact the structural loads in a vegetated roof design?
- A. Green roofing assemblies
- B. Lightning protection system
- C. Fire suppression system
- D. HVAC duct routing
Answer: A
Explanation:
Green roofing adds significant dead loads due to soil and water retention layers. Structural engineers must verify load-bearing capacity. This is tied to ARE Objective 3.2 on evaluating integration of building systems.
NEW QUESTION # 55
Proposed trees along a residential street next to a new development site should first be selected based on which of the following?
- A. Dense root systems and wind resistance
- B. Seasonal foliage, color, and scale
- C. Adaptability to local climate and soil conditions
- D. Provision of natural habitation for local wildlife
Answer: C
Explanation:
Selecting trees for residential streets near a new development should prioritize:
Adaptability to local climate and soil conditions to ensure healthy growth and longevity.
While seasonal foliage, color, scale, and wildlife habitat are important, they are secondary to ensuring the tree can survive and thrive in the environment.
Dense root systems and wind resistance are considerations but often come after adaptability is confirmed.
Reference:
NCARB ARE 5.0 Review Manual, Site Design and Environmental Systems chapter Landscape architecture best practices and local planting guides
NEW QUESTION # 56
In a brick veneer wall, what is the primary purpose of the 2-inch air space between the back of the brick and the sheathing?
- A. To meet the minimum R-value
- B. Minimize mortar bridging
- C. Provide space for roof drain piping
- D. Allow for differential movement
Answer: B
Explanation:
Purpose of the Air Space in Brick Veneer Walls
In a typical brick veneer cavity wall assembly, there is an air space between the back side of the brick and the sheathing (or water-resistive barrier) of the structural wall. This space is typically 1 to 2 inches wide and serves several critical functions:
* Moisture Drainage and Ventilation
* Rainwater can penetrate brick veneer through joints and cracks.
* The air cavity allows water to drain down the back of the veneer to flashing and out through weep holes.
* It also provides ventilation to help dry out the wall assembly.
* Minimizing Mortar Bridging
* During construction, mortar can drop down into the cavity from bricklaying.
* If mortar bridges across to the sheathing, it can create a path for moisture to move into the structure.
* The 2-inch cavity helps reduce the chance that mortar droppings will fully bridge the gap, ensuring the drainage plane stays functional.
Why Other Options Are Incorrect:
* A. To meet the minimum R-value - The air space in brick veneer is not designed as insulation; its thermal benefit is minimal compared to continuous insulation layers.
* B. Allow for differential movement - Brick veneer differential movement is accommodated by wall ties and control joints, not by the air cavity.
* C. Provide space for roof drain piping - Roof drainage piping is routed separately and is not part of the brick veneer cavity design.
NCARB ARE 5.0 PDD Study Guide References:
* Content Area: Building Envelope Systems - Masonry Wall Assemblies
* Source References:
* Building Construction Illustrated (Ching) - Brick Veneer Wall Sections and Cavity Function
* Architectural Graphic Standards - Masonry Veneer Construction Details
* BIA (Brick Industry Association) Technical Notes 21 & 21A - Cavity Wall Design and Construction Key Principle:
A 2-inch air cavity behind brick veneer is primarily to ensure proper drainage and to minimize mortar bridging, which would otherwise allow moisture intrusion into the building.
NEW QUESTION # 57
A family-owned apple farm in the Upper Midwest is taking advantage of a change in the local zoning code that added a new Agri-Tourism class in the existing farm zone. This allows the Owner to build a new facility on their existing site. The building will be open to the public and include a brewery, distillery, tap room, and market. The architect is ready to submit the drawings to the Owner for the 50% construction documents review.
To accommodate a compressed construction schedule, the Owner will be utilizing a design-build process. The Contractor has submitted the Pre-Engineered Metal Building (PEMB) shop drawings to the Architect for review, due to the lead time on this critical path item. Once construction begins, farming operations must be able to continue uninterrupted.
Key project information includes:
* Brewing and distilling will operate year-round.
* Brewery will initially include four fermenting tanks. Owner has requested space for at least two additional tanks. Potential expansion will be based on future sales.
* Distillery will produce 16% alcohol, which is classified as a flammable liquid. Fire separations are required.
* Tap Room is designed with seating for 300 people, not including exterior patio seating. It will have views to the working orchards and the historic buildings on site.
* Tap Room is scheduled to be open from August through November. Owner would like options to extend operating dates based on popularity.
* The Market area will feature local farm products and is not conditioned.
* Entire building will be fully sprinklered.
* Selected building materials are low-maintenance, as requested by the Owner, for durability and to reflect the nature of a working farm.
* Mechanical and electrical systems will be hung from the building structure. These loads are included in PEMB shop drawings.
* Public water and sewer is not available at the Project Site.
* Occupancy sensors are included to reduce utility costs and achieve energy conservation requirements.
The following resources are available for your reference:
* Architectural Drawings, including plans, elevations, sections, and schedules
* Consultant Drawings, including structural, HVAC, power distribution, and plumbing
* PEMB Shop Drawings
* Design and Construction Schedule
* Specification Excerpts, showing relevant spec sections
* IBC and ADA Excerpts, showing relevant code and accessibility sections
* After reviewing the documents, the architect discovers a coordination issue in the corridor.
The owner decides to triple the size of the distillery component of the project to make hand sanitizer and wants to use the Tap Room spaces adjacent to the brewery and distillery for this purpose.
Which of the following must the architect reevaluate and change to accommodate this request? Check the three that apply.
- A. A-04 REFLECTED CEILING PLAN
- B. A-06 EXTERIOR ELEVATIONS
- C. A-03 FLOOR PLAN
- D. A-05 ROOF PLAN
- E. A-01 LIFE SAFETY PLAN
- F. A-02 SITE PLAN
Answer: A,C,E
Explanation:
Tripling the distillery and converting adjacent Tap Room areas to production introduces additional hazard (flammable liquids), changes occupancies/occupant loads, and requires updated fire separations and egress.
A-01 Life Safety Plan must be revised for occupancy classification, fire#resistance ratings between uses, travel distances, exit widths/number, and signage.
A-03 Floor Plan must change to show new room uses, rated partitions/doors, openings, and equipment footprints.
A-04 Reflected Ceiling Plan must change for new/relocated rated assemblies at ceilings (e.g., continuity of fire
/smoke barriers), sprinkler/exit sign/FA device locations, and any duct-damper/access changes.
Site (B), Roof (E), and Elevations (F) are not directly driven by the interior use change.
PDD refs: IBC Chs. 3, 5-10 (occupancy, separation, egress), coordination of architectural, fire protection, and MEP on drawings (Division 01).
NEW QUESTION # 58
The architect has completed 60% of the construction documents. The owner wants to establish the guaranteed maximum price (GMP) at this point before 100% of the construction documents are complete. Several flooring finish items are still undetermined.
What should be included in the project manual to make sure the contractor has a cost to cover all finishes?
- A. Schedule of flooring unit prices to be completed by the contractor
- B. Alternate to change broadloom carpet to carpet tile
- C. Contingency of 10% added to the overall construction cost
- D. Allowance of $30/sq. yd. for floor finishes
Answer: D
Explanation:
When a GMP (Guaranteed Maximum Price) is established before the design is 100% complete and specific materials are not yet chosen, the correct approach is to specify allowances in the project manual.
An allowance is a fixed monetary amount for a specific scope item (e.g., flooring finishes) that allows the contractor to carry a cost in the bid/GMP until the actual product is selected. This ensures the GMP covers the item without delaying pricing.
A). Contingency - Is for unforeseen conditions, not specific unselected finishes.
B). Schedule of unit prices - Typically used for variable-quantity work, not for unknown product selection.
D). Alternate - Provides an option for substitution, but does not guarantee a base cost in the GMP.
PDD Reference: ARE 5.0 PDD "Project Manual and Specifications-Allowances, Alternates, and Unit Prices," AIA A201 §3.8, CSI Division 01-General Requirements.
NEW QUESTION # 59
The design of a 10-story residential building features a curtain wall system on all four elevations. Due to diurnal temperature swings in the area, the curtain wall will need a thermal break to prevent the transfer of heat into the building.
Click on the thermal break in the pressure-plate mullion detail.
Answer:
Explanation:
Explanation:
In the provided pressure-plate curtain wall mullion detail, the thermal break is typically located between the interior and exterior aluminum components of the mullion to prevent conductive heat transfer.
# Thermal Break Location:
Look for the black or dark shaded strip in the middle of the mullion where the two separate metal parts meet - this strip is a non-metallic insulating material (usually polyamide or other plastic) that interrupts the metal-to-metal connection between interior and exterior.
In this image, the thermal break is located:
## In the vertical center of the mullion, between the inner and outer aluminum extrusions, where a black isolator or separator is shown (just above and below the screw/fastener).
Clicking on this narrow dark band (thermal isolator) between the inner and outer components of the curtain wall mullion would be the correct hotspot answer.
NEW QUESTION # 60
Refer to the exhibit.
In the diagram shown, what is the purpose of the pressure relief valve?
- A. Relive negative pressure when draining the tank
- B. Allow for thermal expansion of water
- C. Regulate water pressure fluctuation
- D. Vent the tank of accumulated air
Answer: B
Explanation:
Understanding the Diagram
The diagram shows a water heater (WH) with labeled connections and valves.
Item 2 is the ASME pressure relief valve, piped to 6 inches above the finished floor.
Purpose of the Pressure Relief Valve in a Water Heater
* When water is heated, it expands.
* In a closed plumbing system, this expansion increases pressure inside the water heater tank.
* If the pressure rises above a safe limit, it can damage the heater, piping, or even cause an explosion.
* The temperature and pressure relief valve (T&P valve) automatically opens to discharge water when pressure or temperature exceeds safe limits, relieving the pressure caused by thermal expansion.
Why Other Options Are Incorrect:
* A. Regulate water pressure fluctuation - Pressure regulation is done by a pressure-reducing valve, not a relief valve.
* B. Vent the tank of accumulated air - Air elimination is done with air vents or bleeders, not the T&P valve.
* D. Relieve negative pressure when draining the tank - Negative pressure prevention uses vacuum relief valves, not T&P valves.
NCARB ARE 5.0 PDD Study Guide References:
* Content Area: Plumbing Systems - Equipment and Safety Components
* Source References:
* Plumbing Engineering Design Handbook - Water Heater Safety Devices
* Architectural Graphic Standards - Water Heater Installation Details
* MEEB (Mechanical and Electrical Equipment for Buildings) - Plumbing Chapter: Safety valves in hot water systems
* Code Reference:
* International Plumbing Code (IPC) Section 504.6 - T&P relief valve requirements for water heaters Key Point:
The ASME-rated relief valve's main role is to protect the water heater and piping by relieving excessive pressure due to water expansion from heating.
NEW QUESTION # 61
Option 1 is the originally designed connection detail for a banner hanging system of steel tube beams and threaded rods in a high atrium space. The threaded rod connections to the structure are fabricated as part of the structure. The remaining members are field fabricated. The weights of beam and banner are identical at each level. Option 2 has been proposed to alleviate constructability issues. The structural ramifications must be evaluated before this change can be approved.
Click on the nut in option 2 that will realize a greater load due to the proposed change.
Answer:
Explanation:
Explanation:
The upper nut at the top connection in Option 2 (the nut above the upper tube beam, highlighted at left).
By moving the threaded rod off the member's centroid in Option 2, the connection becomes eccentric. That eccentricity introduces a prying/bending moment at the rod/beam interface in addition to the vertical load from the banner and beam. In a through#rod with a nut above and below the member, the bottom nut primarily resists the direct gravity load in the concentric case (Option 1). When eccentricity is added (Option
2), rotation of the member about the rod induces additional uplift on the top nut (prying action), thereby increasing the force in the top nut relative to the concentric case.
Hence, the nut that will realize the greater load due to the proposed change is the upper nut at the top connection.
References
* NCARB ARE 5.0 PDD Handbook - Structural Systems & Detailing: Connections and eccentric loading.
* AISC Steel Design Guide: Prying Action in Bolted Connections (eccentric connections increase tensile force on the "prying" fastener).
* Ching, Building Construction Illustrated - Steel connections and load paths.
NEW QUESTION # 62
An architect needs to reduce the budget by $150,000 for a proposed civic auditorium. Currently the project requires the following flooring materials:
* Stained concrete: 100,000 square feet
* Carpet: 50,000 square feet
* Ceramic tile: 20,000 square feet
* Vinyl composite tile (VCT): 25,000 square feet
The flooring material costs are as follows:
* Stained concrete: $6.00/sq ft
* Sealed concrete: $2.00/sq ft
* Carpet: $8.75/sq ft
* Ceramic tile: $15.00/sq ft
* VCT: $5.75/sq ft
* Vinyl plank flooring: $7.00/sq ft
Which of the following combinations of changes results in these savings?
- A. Change 20,000 sq ft of stained concrete to VCT and substitute 30,000 sq ft of vinyl plank flooring for carpet.
- B. Change 20,000 sq ft of stained concrete to VCT and substitute 10,000 sq ft of VCT for ceramic tile.
- C. Change 25,000 sq ft of stained concrete to sealed concrete and substitute 30,000 sq ft of vinyl plank flooring for carpet.
- D. Change 15,000 sq ft of VCT to vinyl plank flooring and substitute 10,000 sq ft of VCT for carpet.
Answer: B
Explanation:
Verified answer: C. Change 20,000 sq ft of stained concrete to VCT and substitute 10,000 sq ft of VCT for ceramic tile.
Comprehensive Detailed Explanation with all NCARB ARE 5.0 Project Development and Documentation (PDD) Study Guide References:
Calculate savings for each option by comparing current costs to proposed changes.
Verified answer: C. Change 20,000 sq ft of stained concrete to VCT and substitute 10,000 sq ft of VCT for ceramic tile.
Comprehensive Detailed Explanation with all NCARB ARE 5.0 Project Development and Documentation (PDD) Study Guide References:
Calculate savings for each option by comparing current costs to proposed changes.
Check if this matches required savings:
No, it's less than $150,000. So let's check others briefly.
Total savings = $100,000 + $52,500 = $152,500 # Meets and exceeds required savings
Options A and B will be less, so the answer should be D.
Summary:
Option D results in approximately $152,500 savings, meeting the $150,000 target.
Reference:
NCARB ARE 5.0 Review Manual, Project Cost Control and Materials chapter Construction cost estimating principles and value engineering strategies Change 20,000 sf stained concrete ($6.00/sf) to VCT ($5.75/sf) Savings per sf = $6.00 - $5.75 = $0.25 Total savings = 20,000 sf × $0.25 = $5,000 Substitute 10,000 sf of VCT ($5.75/sf) for ceramic tile ($15.00/sf) Savings per sf = $15.00 - $5.75 = $9.25 Total savings = 10,000 sf × $9.25 = $92,500 Total savings = $5,000 + $92,500 = $97,500 Check if this matches required savings:
No, it's less than $150,000. So let's check others briefly.
Option D:
Change 25,000 sf stained concrete ($6.00/sf) to sealed concrete ($2.00/sf) Savings per sf = $6.00 - $2.00 = $4.00 Total = 25,000 × 4.00 = $100,000 Substitute 30,000 sf vinyl plank ($7.00/sf) for carpet ($8.75/sf) Savings per sf = $8.75 - $7.00 = $1.75 Total = 30,000 × 1.75 = $52,500 Total savings = $100,000 + $52,500 = $152,500 # Meets and exceeds required savings Options A and B will be less, so the answer should be D.
Summary:
Option D results in approximately $152,500 savings, meeting the $150,000 target.
Reference:
NCARB ARE 5.0 Review Manual, Project Cost Control and Materials chapter Construction cost estimating principles and value engineering strategies
NEW QUESTION # 63
Which document is the most appropriate location for specifying the finish material for casework?
- A. Construction Drawings
- B. Outline Specifications
- C. General Conditions
- D. Project Manual - Division 06
Answer: D
Explanation:
Division 06 (Wood, Plastics, and Composites) of the Project Manual contains detailed specifications for finish carpentry and casework materials. This aligns with ARE Objective 2.1: Evaluate project manual sections for technical accuracy.
NEW QUESTION # 64
Refer to the exhibit.
An architect is designing a multipurpose room that will operate daycare services as well as exercise classes.
The multiple occupancies within the space utilize components of the same means of egress system.
What is the occupant load factor that should be used in calculating egress?
- A. 0
- B. 1
- C. 2
- D. 3
Answer: C
Explanation:
Step-by-Step Reasoning
1. Identify the occupancies from the question:
* Day care services # Occupant load factor = 35 net (from table in the exhibit)
* Exercise classes # Occupant load factor = 50 gross (also from table in the exhibit, under "Exercise room")
2. Determine how to calculate the occupant load for multiple occupancies:
According to IBC 2018, Section 1004.1.2 (Areas without fixed seating) and NCARB PDD study materials:
When multiple occupancies share the same means of egress system, the occupant load for the whole space shall be the sum of the occupant loads of the various occupancies.
However, if the space is not divided and is used interchangeably (multipurpose), the most stringent occupant load factor is applied to the entire area.
3. Applying the code:
* The multipurpose room is used for both daycare and exercise.
* Since the same space is used for different functions at different times (not divided), the most restrictive occupant load factor (the smaller number) should be used.
* Smaller occupant load factor = 35 net (Day care) vs. 50 gross (Exercise room).
4. Why "net" vs. "gross" matters here:
* Net floor area excludes certain spaces like walls, corridors, mechanical rooms.
* Gross floor area includes the entire footprint.
* Even though "net" typically results in a smaller area, when calculating load factors, the smaller occupant load factor number results in a larger occupant load - making it more restrictive for egress.
5. Conclusion:
The correct occupant load factor to use for this multipurpose space = 35 net (Day care), as it results in the largest occupant load and is the most restrictive for egress design.
NCARB ARE 5.0 PDD Study Guide References:
* Content Area: Code Analysis - Occupant Load & Egress Sizing
* IBC 2018, Section 1004.1.2 - Areas without fixed seating, determining occupant load for multiple functions
* Architectural Graphic Standards - Occupant Load Calculation examples
* Building Codes Illustrated by Ching & Winkel - Chapter on Occupancy Load Factors and Egress Requirements
NEW QUESTION # 65
A family-owned apple farm in the Upper Midwest is taking advantage of a change in the local zoning code that added a new Agri-Tourism class in the existing farm zone. This allows the Owner to build a new facility on their existing site. The building will be open to the public and include a brewery, distillery, tap room, and market. The architect is ready to submit the drawings to the Owner for the 50% construction documents review.
To accommodate a compressed construction schedule, the Owner will be utilizing a design-build process. The Contractor has submitted the Pre-Engineered Metal Building (PEMB) shop drawings to the Architect for review, due to the lead time on this critical path item. Once construction begins, farming operations must be able to continue uninterrupted.
Key project information includes:
* Brewing and distilling will operate year-round.
* Brewery will initially include four fermenting tanks. Owner has requested space for at least two additional tanks. Potential expansion will be based on future sales.
* Distillery will produce 16% alcohol, which is classified as a flammable liquid. Fire separations are required.
* Tap Room is designed with seating for 300 people, not including exterior patio seating. It will have views to the working orchards and the historic buildings on site.
* Tap Room is scheduled to be open from August through November. Owner would like options to extend operating dates based on popularity.
* The Market area will feature local farm products and is not conditioned.
* Entire building will be fully sprinklered.
* Selected building materials are low-maintenance, as requested by the Owner, for durability and to reflect the nature of a working farm.
* Mechanical and electrical systems will be hung from the building structure. These loads are included in PEMB shop drawings.
* Public water and sewer is not available at the Project Site.
* Occupancy sensors are included to reduce utility costs and achieve energy conservation requirements.
The following resources are available for your reference:
* Architectural Drawings, including plans, elevations, sections, and schedules
* Consultant Drawings, including structural, HVAC, power distribution, and plumbing
* PEMB Shop Drawings
* Design and Construction Schedule
* Specification Excerpts, showing relevant spec sections
* IBC and ADA Excerpts, showing relevant code and accessibility sections
* After reviewing the documents, the architect discovers a coordination issue in the corridor.
The owner has revised the pro forma and directed the architect to add two additional Type B units to the design. A code review for the project indicates that the building occupancy is R-2.
What should the architect do to meet the owner's required revisions?
- A. Change the 10th Floor Unit 2BR-E to two 1-bedroom units and change the 7th Floor Unit 2BR-E to two
1-bedroom units. - B. Change the 2nd Floor Unit 1BR-SW into two studios and change the 10th Floor Unit 2BR-E to two 1- bedroom units.
- C. Change the 5th Floor Unit 2BR-E to two 1-bedroom units and change the 2nd Floor Laundry to a 1- bedroom unit.
Answer: A
Explanation:
Converting two existing 2-bedroom units into two 1-bedroom units each yields two additional dwelling units total, while keeping every unit on an exterior wall for light/vent and maintaining typical plumbing stacks
/egress.
A introduces two studios (size/layout risk) and alters a lower-floor stack; more coordination risk.
C converts a Laundry (likely interior and serving the building) into a unit-problematic for light/ventilation and building services.
PDD refs: IBC R-2 unit planning, light/ventilation, egress; planning & stacking strategies to minimize rework.
NEW QUESTION # 66
In the design of a barrier-free access route, door locksets should be equipped with which one of the following?
- A. Knurled knobs
- B. Panic devices
- C. Lever handles
- D. Grip handles with thumbpieces
Answer: C
Explanation:
For barrier-free (ADA) accessible routes, operable parts such as door hardware must be usable with one hand and not require tight grasping, pinching, or twisting of the wrist (2010 ADA Standards §404.2.7). Lever handles meet this requirement because they can be operated by users with limited grip strength or dexterity.
A). Grip handles with thumbpieces - Often require pinching or twisting; not compliant for barrier-free.
B). Knurled knobs - Non-compliant because they require twisting and strong grip; also typically used for hazardous rooms as a tactile warning.
D). Panic devices - Allowed in certain egress conditions but not the universal ADA hardware requirement for standard accessible doors.
PDD Reference: ARE 5.0 Handbook, PDD "Codes and Regulations-Accessibility," 2010 ADA Standards
§404.2.7, ICC A117.1 Accessibility Standard.
NEW QUESTION # 67
Which of the following documents would the architect need in order to prepare the specifications?
- A. Geotechnical report, building sections, and room finish schedule
- B. Legal survey, geotechnical report, and traffic management plan
- C. Legal survey, engineering drawings, and door schedule
- D. Architectural floor plans, room finish schedule, and traffic management plan
Answer: A
Explanation:
To prepare project specifications, the architect requires documents that inform about site conditions, building construction, and interior finishes:
Geotechnical report provides soil conditions, foundation recommendations, and site constraints.
Building sections provide detailed information on assemblies, materials, and vertical relationships.
Room finish schedule identifies finishes, materials, and related specifications for interior spaces.
Legal surveys, traffic management plans, and door schedules are important for planning and design coordination but less directly informative for writing specifications.
References:
NCARB ARE 5.0 Review Manual, Project Development and Documentation chapter CSI Construction Specifications Practice guides Project delivery and documentation best practices
NEW QUESTION # 68
Which of the following metals is best suited for embedments in concrete or masonry?
- A. Cast iron
- B. Bronze
- C. Stainless steel
- D. Aluminum
Answer: C
Explanation:
When metals are embedded in concrete or masonry, corrosion resistance is a critical factor due to the alkaline environment and potential moisture exposure.
Stainless steel has excellent corrosion resistance, making it ideal for embedments in concrete or masonry where long-term durability is required.
Bronze is corrosion-resistant but typically used for decorative or hardware applications, not structural embedments.
Aluminum corrodes readily in alkaline concrete environments and is not suitable for embedments without protective coatings.
Cast iron is susceptible to rust and corrosion in moist conditions and is generally avoided for embedded components.
Thus, stainless steel is best suited for durability and corrosion resistance in concrete/masonry embedments.
References:
NCARB ARE 5.0 Review Manual, Materials and Assemblies chapter
Building construction materials standards (ACI, ASTM) on metals in concrete Corrosion resistance guides for metals embedded in concrete
NEW QUESTION # 69
......
PDD Premium Exam Engine pdf Download: https://www.prepawayete.com/NCARB/PDD-practice-exam-dumps.html
PDD Exam [2025] Dumps NCARB PDF Questions: https://drive.google.com/open?id=1pFbmeFopV-EYpapFRQLhtZ94A_ieL4Mg
